一、Rectifier的简介 整流管，是有两个电极的装置，只允许电流由单一方向流过，许多的使用是应用其整流的功能。可分为:普通整流管、快恢复整流管、超快速恢复整流管、肖特基管和桥式整流器。 二、整流管的选用技巧 1.根据电路电压选择合适的lfsm和Vrm; 2. Vf 小比大好; 3.根据电路需要选择TRR和封装。 |
| Part Number |
Vr MAX(V)
|
If (AV)
|
Ifsm(A)
|
Vf(V)
|
Ir(Ta=25℃)
|
Package
|
Inner Diagram | Data sheet |
|---|---|---|---|---|---|---|---|---|
| SLT60M45CT | 45 | 60 | 275 | 0.52 | 450uA | TO-220-3L |
 |
|
| S-DSS16L | 60 | 1 | 30 | 0.55 | 0.5 | SOD-123FL |
 |
|
| RB751S-40 | 40 | 30 | 200 | 0.37 | 1 | SOD-523 |
 |
|
| S-M7 | 1000 | 1 | 30 | 1.1 | 5 | SMA |
 |
|
| S-M7 | 1000 | 1 | 30 | 1.1 | 5 | SMA |
|
|
| S-DSK12 | 20 | 1 | 25 | 0.5 | 0.5 | SOD-123FL |
 |
|
| MBRD3200S | 200 | 3 | 50 | 0.85 | 0.05 | TO-252 |
 |
|
| EP1060F | 600 | 10 | 100 | 2.3 | 5 | TO-220AC |
 |
|
| DSK26L | 60 | 2 | 50 | 0.5 | 0.3 | SOD-123FL |
 |
|
| DSK220L | 200 | 2 | 50 | 0.85 | 0.1 | SOD-123FL |
 |
|
| DSK210H | 200 | 2 | 50 | 0.95 | 1 | SOD-123FL |
 |
|
| SMF4753A | 27.4 | 1.2 | 0.5 | SOD-123FL |
 |
|||
| LMAK4P50 | TO-252 |
 |
||||||
| B1040X | 40 | 7 | 0.61 | 40 | SOD-523 |
 |
||
| S-DS1M | 1000 | 1 | 25 | 1.1 | 5 | SOD-123FL |
 |
|
| S-DSK210 | 100 | 2 | 50 | 0.85 | 0.1 | SOD-123FL |
 |
|
| S-DSK14L | 40 | 1 | 30 | 0.42 | 1000 | SOD-123FL |
 |
|
| BAS516 | 75 | 125 | 2 | 1.25 | 30 | SOD-523 |
 |
|
| BZX584C5V6 | 1 | 10 | 0.085 | 4 | SOD-523 |
 |
||
| BAS70-05 | 70 | 70 | 100 | 410 | 100 | SOT-23 |
 |
|
| SM5819WS | 40 | 3 | 9 | 0.9 | 1 | SOD-323 |
 |
|
| S-LA7 | 700 | 1 | 30 | 1 | 2 | SOD-123FL |
 |
|
| 1.5SMP26A | 26 | 200 | 3.5/5 | 5 | TO-277 |
 |
||
| MBR1645F | 45 | 150 | 0.63 | 0.5 | TO-220AC |
 |
||
| SR36 | 60 | 60 | 0.62 | 0.5 | SMB |
 |
||
| U7 | 1000 | 35 | 35 | 1.7 | 5 | SOD-123FL |
 |
|
| SMA3Z15A | 11.4 | 0.5 | 1.2 | 0.5 | SMA |
 |
||
| SS23LB | 30 | 2 | 100 | 0.45 | 0.3 | SMB |
 |
|
| SS2U40WS | 40 | 2 | 20 | 0.37 | 80 | SOD-323 |
 |
|
| S-DSK16L | 60 | 1 | 40 | 0.52 | 0.5 | SOD-123FL |
 |
